Q-100-0680

Pallet cart with rollers - 2030 x 770 mm

Custom designed cart for transitioning pallets and containers.

Technical specifications

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Type of tow bar: Tongue and Hitch

Category: Conveyor

Width: 30 inch

Length: 80 inch

Load capacity: 595 lbs

Transportation method: Tugger

Caster size: 5 inch

Caster Type: Polyurethane

More info

This cart is equipped with steel rollers so that the materials can be easily slid on and off the cart. It comes with a drop pin and hitch tow bar, so it can be transported via a tugger train system.

Parts included
FlexTube™ 70 mm - Locking Nut 2 Q-000-1101
FlexTube™ 1120 mm 1 Q-000-1258
FlexTube™ 910 mm 1 Q-000-1269
FlexQube 4 Q-001-1078
FlexBeam™ 1190 mm 4 Q-001-1300
FlexBeam™ 770 mm 4 Q-001-1306
FlexBeam™ 770 mm FE 2 Q-001-1406
FlexBeam™ 630 mm FE 4 Q-001-1408
FlexPlate™ 20 Q-002-1001
Flexplate™ M10 5 Q-002-1162
Caster Polyurathane 125 mm 80 x 60 Swivel 3 Q-004-1220
Caster Polyure. 125 mm 80 x 60 Fixed 3 Q-004-1221
L Bracket Joint 4 Q-005-0031
Foot pedal 1 Q-005-0236
Rotation handle and lock - 350 mm 1 Q-005-0239
Caster to Beam Attachment - 80 x 60 mm 6 Q-005-0265
Locking Guide Plate 1 Q-005-0290
Towing Hole 2 Q-005-1056
Spring for Tow Bar 2 Q-005-1070
Rotation Handle and Lock - 242,5 mm 1 Q-005-1354
64 mm FlexBeam™ Collet 15 Q-005-1426
Pallet cart with rollers - 2030 x 770 mm 52 Q-100-0680
M10 Lifting Eye Bolt - 17 mm 2 Q-006-0020
Allen Head - M6 x 30 mm 1 Q-006-1012
Hex Head - M20 x 500 mm 1 Q-006-1016
M6 x 20 K6S 10.9 Round Head (black) 8 Q-006-1018
Hex Head - M14 x 60 mm 2 Q-006-1036
Locking Nut M14 2 Q-006-1039
Hex Head - M10 x 25 mm 2 Q-006-1041
Locking Nut M10 37 Q-006-1042
Locking Nut M6 13 Q-006-1050
Hex Head - M10 x 95 mm 9 Q-006-1088
Hex Head - M10 x 90 mm 2 Q-006-1132
Hex Head - M10 x 30 mm 2 Q-006-1161
Locking Nut M8 24 Q-006-1181
Nut M10 1 Q-006-1195
Hex Head - M10 x 20 mm 8 Q-006-1232
Countersunk - M8 x 20 24 Q-006-1282
Hex Head Fully Threaded - M10 x 50 mm 1 Q-006-1343
Extra Low Head - M10 x 90 mm 9 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 128 Q-006-1384
M20 Locking Nut 1 Q-006-1405
Hex Head Fully Threaded - M10 x 60 mm 2 Q-006-1502
Compression Spring for US Tow Hitch 1 Q-012-0007
Tow Bar Pull Spring - 245 mm 1 Q-012-0008
US Modular Tow Bar VKR - 950 mm 1 Q-017-0002
Handle for Tow Hole 1 Q-017-0022
Towing Lip - 28 mm 1 Q-017-1010
Tow Attachment to Beam 1 Q-017-1080
Tow Hinge 1 Q-017-1083
