Back Back Q-100-0568 Tugger Cart 48 x 45 inch Standard tugger cart designed with steel flat deck. Get a quote 100% free. No commitment. Get a quote Close Tugger Cart 48 x 45 inch Email Phone Location Comments (optional) Attach a file (optional) Upload Maximum file size is 10mb. We will get back to you within 24 hours. (Unless it’s during holidays.) Create your own cart Boost Efficiency Heavy-duty & modular Technical specifications Transportation method Manual, Tugger Industry Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy Length 49 inch Width 47 inch Load capacity 2205 lbs Caster size 8 inch Parts included FlexBeam™ 1120 mm 6 Q-001-1301 FlexBeam™ 1260 mm FE 2 Q-001-1500 FlexPlate™ 4 Q-002-1001 Flexplate™ M10 3 Q-002-1162 Wheel Attachment - 105 x 77,5 mm 2 Q-004-1065 Caster Polyurethane - 200 mm 4 Q-004-1100 Caster Polyurethane 200 mm Fixed 2 Q-004-1101 Floor Brake LTL - 200 mm 1 Q-004-1359 Towing Hole 2 Q-005-1056 Spring for Tow Bar 2 Q-005-1070 Wheel Attachment Box 6 Q-005-1079 Pallet Guide Corner Plate 4 Q-005-1096 64 mm FlexBeam™ Collet 12 Q-005-1426 Washer M20 2 Q-006-0016 Allen Head - M6 x 30 mm 1 Q-006-1012 Hex Head - M14 x 60 mm 4 Q-006-1036 Locking Nut M14 4 Q-006-1039 Hex Head - M10 x 25 mm 46 Q-006-1041 Locking Nut M10 80 Q-006-1042 Washer M10 12 Q-006-1043 Locking Nut M6 1 Q-006-1050 Hex Head - M10 x 95 mm 3 Q-006-1088 Hex Head - M10 x 90 mm 5 Q-006-1132 Hex Head - M10 x 30 mm 6 Q-006-1161 Nut M10 1 Q-006-1195 Hex Head Fully Threaded - M10 x 50 mm 1 Q-006-1343 Extra Low Head - M10 x 90 mm 7 Q-006-1381 Self Tapping Screw M6 Torx H60 x 16 72 Q-006-1384 Extra Low Head Allen - M10 x 25 mm 12 Q-006-1410 Compression Spring for US Tow Hitch 1 Q-012-0007 Handle With Bent Top + Floor Brake (North America) 1 Q-015-1060 Half Top Plate - 49 x 23 inch 2 Q-016-0269 US Modular Tow Bar VKR - LIP - 520 mm 1 Q-017-0014 Handle for Tow Hole 1 Q-017-0022 Cotter Pin - 3,2 x 32 mm 2 Q-017-0023 Towing Lip - 28 mm 1 Q-017-1010 Tow Bar Lock Tube - 498 mm 1 Q-017-1061 Tow Attachment to Beam 1 Q-017-1080 Tow Hinge 1 Q-017-1083 Show all More info This tugger tugger was designed for transporting pallets and containers. It comes equipped with an ergonomic handlebar for easier manual transportation. There is also a drop pin and hitch tow bar for transportation via a tugger train system. Six high quality polyurethane casters are also attached for improved tracking when in a tugger train.
