Tugger Cart - 32 x 30 Inch
Tugger Cart - 32 x 30 Inch
Tugger Cart - 32 x 30 Inch
Tugger Cart - 32 x 30 Inch
Q-100-0716

Tugger Cart - 32 x 30 Inch

Standard tugger cart designed for transporting containers and bins.

Technical specifications

Category: Standard

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Type of tow bar: Tongue and Hitch

Width: 30 inch

Length: 33 inch

Load capacity: 2205 lbs

Transportation method: Manual, Tugger

Caster size: 5 inch

Caster Type: Polyurethane

Type of Load: Bins, Pallets and Containers

More info

This smaller tugger cart is equipped with an ergonomic handlebar for improved manual pushing. It is designed for improving transportation of containers and bins within facilities. It also comes equipped with a drop pin and hitch tow bar so it can be towed in a tugger train.

Parts included
FlexBeam™ 770 mm 4 Q-001-1306
FlexBeam™ 770 mm FE 2 Q-001-1406
FlexBeam™ 630 mm FE 2 Q-001-1408
FlexPlate™ 4 Q-002-1001
Caster Polyurathane 125 mm 80 x 60 Swivel 2 Q-004-1220
Caster Polyure. 125 mm 80 x 60 Fixed 2 Q-004-1221
Floor Lock COLSON 4 x 4-1/2 1 Q-004-1369
Angle corner plate - 5 mm 2 Q-005-0227
Caster to Beam Attachment - 80 x 60 mm 4 Q-005-0265
M8 Damper - GN352-30-25-M8-S-55 1 Q-005-0648
Towing Hole 2 Q-005-1056
Left Angle Corner Plate 1 Q-005-1097
Right Angle Corner Plate 1 Q-005-1099
64 mm FlexBeam™ Collet 18 Q-005-1426
Allen Head - M6 x 30 mm 1 Q-006-1012
Washer 10,5 x 30 x 2,5 1 Q-006-1030
Hex Head - M14 x 60 mm 2 Q-006-1036
Locking Nut M14 2 Q-006-1039
Hex Head - M10 x 25 mm 6 Q-006-1041
Locking Nut M10 33 Q-006-1042
Washer M10 6 Q-006-1043
Locking Nut M6 1 Q-006-1050
Hex Head - M10 x 95 mm 2 Q-006-1088
Hex Head - M10 x 90 mm 4 Q-006-1132
Hex Head - M10 x 30 mm 2 Q-006-1161
Locking Nut M8 17 Q-006-1181
M8 x 16 mm Countersunk 16 Q-006-1214
Extra Low Head - M10 x 90 mm 12 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 16 Q-006-1384
Extra Low Head Allen - M10 x 25 mm 4 Q-006-1410
Hex Head Fully Threaded - M10 x 60 mm 3 Q-006-1502
Compression Spring for US Tow Hitch 1 Q-012-0007
Handle With Bent Top + Floor Brake (North America) 1 Q-015-1060
US Modular Tow Bar VKR - Lip - 380 mm 1 Q-017-0015
Handle for Tow Hole 1 Q-017-0022
Tow Hinge Module 1 Q-017-0059
Towing Lip - 28 mm 1 Q-017-1010
