Flat Deck Engine Cart - 50 x 58 inch
Flat Deck Engine Cart - 50 x 58 inch
Flat Deck Engine Cart - 50 x 58 inch
Flat Deck Engine Cart - 50 x 58 inch
Q-100-0497

Flat Deck Engine Cart - 50 x 58 inch

Custom flat deck tugger cart for engines.

Technical specifications

Category: Flat Deck

Industry: Automotive, Commercial Vehicles, Tier One Suppliers

Width: 50 inch

Length: 58 inch

Load capacity: 1102 lbs

Transportation method: Manual, Tugger

Caster size: 8 inch

Caster Type: Polyurethane

Type of Load: Pallets and Containers

More info

This custom cart was originally designed to transport engines, but it can also be used to transport pallets and containers. It comes equipped with an ergonomic handlebar for easier manual transportation. It also comes with a foot release tow bar for transportation via a tugger train. The purpose of the foot release is to improve ergonomics and reduce bending/flexing by the operators.

Parts included
FlexTube™ 70 mm - Locking Nut 12 Q-000-1101
FlexBeam™ - 1400 mm 6 Q-001-1297
FlexBeam™ 1260 mm FE 2 Q-001-1500
FlexPlate™ 6 Q-002-1001
Stiffener - Outside 4 Q-002-1050
Wheel Attachment - 105 x 77,5 mm 8 Q-004-1065
Caster Polyurethane - 200 mm 4 Q-004-1100
Caster Polyurethane 200 mm Fixed 2 Q-004-1101
Floor Brake LTL - 200 mm 1 Q-004-1359
Spring Cover Plate 1 Q-005-1025
Spring for Tow Bar 2 Q-005-1070
Hex Head M14 x 90 mm 1 Q-005-1406
64 mm FlexBeam™ Collet 4 Q-005-1426
Washer M20 2 Q-006-0016
Hex Head - M14 x 60 mm 2 Q-006-1036
Locking Nut M14 3 Q-006-1039
Hex Head - M10 x 25 mm 10 Q-006-1041
Locking Nut M10 55 Q-006-1042
Washer M10 12 Q-006-1043
Hex Head - M10 x 95 mm 8 Q-006-1088
Hex Head - M8 x 16 mm 6 Q-006-1120
Hex Head - M10 x 90 mm 16 Q-006-1132
Hex Head - M10 x 30 mm 4 Q-006-1161
Locking Nut M8 6 Q-006-1181
Nut M10 1 Q-006-1195
Hex Head Fully Threaded - M10 x 50 mm 1 Q-006-1343
Extra low head [1,5 mm] M10x40 mm 12 Q-006-1361
Extra Low Head - M10 x 90 mm 4 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 110 Q-006-1384
Extra Low Head Allen - M10 x 25 mm 8 Q-006-1410
Hex Head Fully Threaded - M10 x 60 mm 4 Q-006-1502
Spring 1,5 x 15yd x 70 1 Q-012-1141
Handlebar / Floor Brake Attachment US 1 Q-015-0029
Handlebar Attachment US 1 Q-015-0031
Tube for Handlebar US 1 Q-015-0032
Gaurd rail plate - 1250 x 735 mm 2 Q-016-0238
US Modular Tow Bar VKR - Foot Release - 670 mm 1 Q-017-0012
Cotter Pin - 3,2 x 32 mm 2 Q-017-0023
Foot Release Locking Lip 1 Q-017-0024
Locking lip attachment 1 Q-017-1043
Tow Bar Lock Tube - 498 mm 1 Q-017-1061
Tow Hole 28 mm - Symmetric 1 Q-017-1066
Tow Attachment to Beam 1 Q-017-1080
Tow Hinge 1 Q-017-1083
Towing Lock Pin US 1 Q-017-1105
39 mm Sleeve for M10 US 2 Q-017-1106
