Tugger Cart - 1260 x 1190 mm
Tugger Cart - 1260 x 1190 mm
Tugger Cart - 1260 x 1190 mm
Tugger Cart - 1260 x 1190 mm
Q-100-0708

Tugger Cart - 1260 x 1190 mm

Standard tugger cart designed for moving pallets and containers.

Technical specifications

Category: Standard

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Type of tow bar: Tongue and Hitch

Width: 47 inch

Length: 50 inch

Load capacity: 2205 lbs

Transportation method: Manual

Caster size: 8 inch

Caster Type: Polyurethane

More info

This tugger cart is used for transporting heavy pallets and containers. There are six high quality polyurethane casters attached, two of them are fixed to improve tracking when in a train. It also comes with a drop pin and hitch tow bar and an ergonomic handlebar.

Parts included
FlexBeam™ 1120 mm 6 Q-001-1301
FlexBeam™ 1260 mm FE 2 Q-001-1500
FlexPlate™ 4 Q-002-1001
Wheel Attachment - 105 x 77,5 mm 2 Q-004-1065
Caster Polyurethane - 200 mm 4 Q-004-1100
Caster Polyurethane 200 mm Fixed 2 Q-004-1101
Floor Brake LTL - 200 mm 1 Q-004-1359
M8 Damper - GN352-30-25-M8-S-55 1 Q-005-0648
Towing Hole 2 Q-005-1056
Wheel Attachment Box 6 Q-005-1079
Pallet Guide Corner Plate 4 Q-005-1096
64 mm FlexBeam™ Collet 12 Q-005-1426
Allen Head - M6 x 30 mm 1 Q-006-1012
Washer 10,5 x 30 x 2,5 1 Q-006-1030
Hex Head - M14 x 60 mm 2 Q-006-1036
Locking Nut M14 2 Q-006-1039
Hex Head - M10 x 25 mm 46 Q-006-1041
Locking Nut M10 79 Q-006-1042
Washer M10 2 Q-006-1043
Locking Nut M6 1 Q-006-1050
Hex Head - M10 x 90 mm 8 Q-006-1132
Hex Head - M10 x 30 mm 2 Q-006-1161
Locking Nut M8 1 Q-006-1181
Hex Head Fully Threaded - M10 x 50 mm 3 Q-006-1343
Extra Low Head - M10 x 90 mm 8 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 16 Q-006-1384
M20 Locking Nut 1 Q-006-1405
Compression Spring for US Tow Hitch 1 Q-012-0007
Handlebar Attachment EUR 1 Q-015-0026
Handlebar / Floor brake attachment EUR 1 Q-015-0027
Tube for Handlebar EUR 1 Q-015-0033
Handle for Tow Hole 1 Q-017-0022
EUR modular Tow bar VKR - Lip - 520 mm 1 Q-017-0031
Tow Hinge Module 1 Q-017-0059
Towing Lip - 28 mm 1 Q-017-1010
