Transfer Cart - 1330 x 1260 mm
Transfer Cart - 1330 x 1260 mm
Transfer Cart - 1330 x 1260 mm
Transfer Cart - 1330 x 1260 mm
Q-100-1327

Transfer Cart - 1330 x 1260 mm

Tuggable kit cart used for long plates/panels and totes. The cart is equipped with four polyurethane casters, two fixed and two swivel giving it excellent tracking properties when connected in a train.

Technical specifications

Category: Specialized Carts

Transportation method: Manual, Tugger

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Type of tow bar: Tongue and Hitch

Length: 52 inch

Width: 50 inch

Load capacity: 331 lbs

Caster size: 5 inch

Caster Type: Polyurethane

More info

Tuggable kit cart used for transportation of plates/panels as well as totes and boxes. The plates and panels can be placed on the left side between tubes that have been covered in plastic to prevent the parts from being damaged and the totes can be placed on the shelves on the right side. The cart is also equipped with four high quality polyurethane casters, two fixed and two swivel which gives the cart excellent tracking properties and silent movement when connected in a train.

Parts included
FlexBeam™ 1190 mm 4 Q-001-1300
FlexBeam™ 1190 mm FE 6 Q-001-1400
FlexBeam™ 1120 mm FE 8 Q-001-1401
FlexBeam™ 1050 mm FE 4 Q-001-1402
FlexBeam™ 770 mm FE 4 Q-001-1406
FlexBeam™ 560 mm FE 4 Q-001-1409
FlexBeam™ - 1330 mm FE 2 Q-001-1501
FlexBeam STS FE - 1680 mm 8 Q-001-1506
FlexPlate™ 8 Q-002-1001
Flexplate™ M10 23 Q-002-1162
Caster Polyurathane 125 mm 80 x 60 Swivel 2 Q-004-1220
L Bracket Joint 4 Q-005-0031
Caster to Beam Attachment - 80 x 60 mm 4 Q-005-0265
L-Bracket Joint - 70 x 70 mm 6 Q-005-0429
Spring Threaded Tube Connectors 29 Q-005-0469
Triangle Joint 20 Q-005-0483
Flexible Vinyl Push - On Round Caps 21 Q-005-0728
Plastic Tube - 1120 mm 2 Q-005-0771
Plastic Protection M10 - 95 mm 8 Q-005-0882
Spherical Knob 8 Q-005-1146
Beam to Beam Corner Plate 2 Q-005-1356
64 mm FlexBeam™ Collet 64 Q-005-1426
Heavy Duty Joint M10 6 Q-005-1580
Hex Head - M14 x 60 mm 4 Q-006-1036
Fully Threaded - M10 x 120 mm 12 Q-006-1037
Locking Nut M14 4 Q-006-1039
Hex Head - M10 x 25 mm 6 Q-006-1041
Locking Nut M10 122 Q-006-1042
Washer M10 2 Q-006-1043
Hex Head - M10 x 95 mm 6 Q-006-1088
Hex Head - M10 x 90 mm 68 Q-006-1132
Locking Nut M8 16 Q-006-1181
Nut M10 8 Q-006-1195
M8 x 16 mm Countersunk 16 Q-006-1214
Hex Head - M10 x 20 mm 6 Q-006-1232
Extra Low Head - M10 x 90 mm 34 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 310 Q-006-1384
Extra Low Head Allen - M10 x 25 mm 23 Q-006-1410
Top plate - 1260 x 490 mm 1 Q-016-0694
Top plate - 1330 x 1260 mm 1 Q-016-0695
US Modular Tow Bar VKR - LIP - 520 mm 1 Q-017-0014
Spring Loaded Tow Hinge 1 Q-017-0067
Heavy Duty Tow Hinge - Narrow 1 Q-017-0087
Towing Lip - 28 mm 1 Q-017-1010
Outer Tube (No Plate) - 840 mm 21 Q-025-0840
Outer Tube (No Plate) - 1120 mm 2 Q-025-1120
