Shelf Cart W. Divider - 1260 x 3430 mm

Four level flat shelf tugger cart equipped with a tow bar, handlebar, floor brake and six high quality polyurethane casters.

Technical specifications

Category: Flat Shelf

Transportation method: Manual

Industry: Appliances & Electronics, Distribution, Medical Equipment

Length: 135 inch

Levels: 3

Load capacity: 1984 lbs

Load Capacity per Level: 661 lbs

Width: 50 inch

Caster size: 8 inch

Caster Type: Polyurethane

More info

Robust tuggable flat shelf cart with four levels commonly used for transportation of totes/bins/boxes or loose components. The shelves are divided into sixteen sections to make it easier to separate the products. The cart is also equipped with a tow bar, handlebar, floor brake and six high quality polyurethane casters which gives the cart excellent tracking properties and silent movement when connected in a train.

Parts included
FlexBeam STS - 2030 mm 4 Q-001-1288
FlexBeam™ - 1330 mm 4 Q-001-1298
FlexBeam™ 1120 mm FE 4 Q-001-1401
FlexBeam™ 1260 mm FE 2 Q-001-1500
FlexBeam™ - 1470 mm FE 12 Q-001-1503
FlexPlate™ 32 Q-002-1001
Wheel Attachment - 105 x 77,5 mm 8 Q-004-1065
Caster Polyurethane - 200 mm Swivel 4 Q-004-1211
Caster Polyurethan 200 mm Fixed IP2 2 Q-004-1212
US Floor Brake - 200 mm 1 Q-004-1613
L Bracket Joint 2 Q-005-0031
Triangle Joint 4 Q-005-0483
Flat Divider For Shelf - 625 mm 64 Q-005-0902
Spring Cover Plate 1 Q-005-1025
Beam to Beam Corner Plate 4 Q-005-1356
Hex Head M14 x 90 mm 1 Q-005-1406
64 mm FlexBeam™ Collet 60 Q-005-1426
Hex Head Fully Threaded - M8 x 20 mm 48 Q-006-1019
Hex Head - M14 x 60 mm 2 Q-006-1036
Locking Nut M14 3 Q-006-1039
Hex Head - M10 x 25 mm 2 Q-006-1041
Locking Nut M10 174 Q-006-1042
Washer M10 8 Q-006-1043
Hex Head - M10 x 95 mm 10 Q-006-1088
Hex Head - M8 x 16 mm 72 Q-006-1120
Hex Head - M10 x 90 mm 62 Q-006-1132
Hex Head - M10 x 30 mm 4 Q-006-1161
Locking Nut M8 120 Q-006-1181
M8 Washer 96 Q-006-1183
Extra Low Head - M10 x 90 mm 24 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 320 Q-006-1384
Low Allen Head - M10 x 16 mm 66 Q-006-1409
Extra Low Head Allen - M10 x 25 mm 4 Q-006-1410
Hex Head Fully Threaded - M10 x 60 mm 2 Q-006-1502
Spring 1,5 x 15yd x 70 1 Q-012-1141
Handlebar / Floor Brake Attachment US 1 Q-015-0029
Handlebar Attachment US 1 Q-015-0031
Tube for Handlebar US 1 Q-015-0032
Angled plate - 1738 mm 16 Q-016-0193
Flat Shelf - 1260 x 1645 mm 8 Q-016-0688
Shelf Divider -140 x 1590 mm 8 Q-016-0689
US Modular Tow Bar VKR - Foot Release - 670 mm 1 Q-017-0012
Foot Release Locking Lip 1 Q-017-0024
Heavy Duty Tow Hinge - Narrow 1 Q-017-0087
Tow Hole 28 mm - Symmetric 1 Q-017-1066
Towing Lock Pin US 1 Q-017-1105
39 mm Sleeve for M10 US 2 Q-017-1106
