Matrerial Presentation Rack 1960 x 8450 mm
Material Presentation Rack 1960 x 840 mm
Material Presentation Rack 1960 x 840 mm
Material Presentation Rack 1960 x 840 mm
Material Presentation Rack 1960 x 840 mm
Material Presentation Rack 1960 x 840 mm
Material Presentation Rack 1960 x 840 mm
Q-100-0456

Material Presentation Rack 1960 x 840 mm

Rack for material presentation. The two top levels are used for incoming material and the bottom levels for empty totes and boxes. Equipped with four nylon swivel casters.

100% free. No commitment.

Automotive 450 lbs
load capacity
Get a quote
Close

Material Presentation Rack 1960 x 840 mm

Maximum file size is 10mb.

We will get back to you within 24 hours. (Unless it’s during holidays.)

Technical specifications
Category Flow Rack
Transportation method Manual
Industry Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy
Width 33 inch
Length 77 inch
Levels 3
Load capacity 450 lbs
Load Capacity per Level 150 lbs
Caster size 5 inch
Caster Type Gray
More info

This rack was designed to be used next to a workstation for the storage and presentation of totes. The two top levels are used for incoming material and the bottom levels for the return of empty totes and boxes. The cart is equipped with four nylon swivel casters and two handlebars making it easy to maneuver in tight areas.

Parts included
FlexTube™ 700 mm 2 Q-000-1002
FlexTube™ 350 mm 1 Q-000-1055
FlexTube™ 70 mm - Locking Nut 2 Q-000-1101
FlexTube™ 490 mm 2 Q-000-1247
FlexTube™ 1120 mm 4 Q-000-1258
FlexTube™ 280 mm 1 Q-000-1262
FlexTube™ 770 mm 1 Q-000-1265
FlexTube™ 420 mm 5 Q-000-1270
FlexTube™ 630 mm 4 Q-000-1312
FlexTube™ 980 mm 2 Q-000-1399
FlexQube 24 Q-001-1078
FlexBeam™ - 1610 mm 4 Q-001-1294
FlexBeam™ 980 mm FE 4 Q-001-1403
FlexBeam™ 840 mm FE 2 Q-001-1405
FlexBeam™ 770 mm FE 4 Q-001-1406
FlexBeam™ 490 mm FE 4 Q-001-1410
FlexPlate™ 6 Q-002-1001
Flexplate™ M10 8 Q-002-1162
Roller - 450 mm 26 Q-003-0014
Roller Guide 10 mm offset - 650 mm 8 Q-003-0017
Roller Guide 10 mm offset - 375 mm 15 Q-003-0018
Rail Support No Stop 36 Q-003-1021
Rail Support Drop 30 mm Stop 36 Q-003-1022
Swivel Caster - 125 mm 2 Q-004-1363
125 mm Swivel Caster with Brake 2 Q-004-1364
T-Joint 4 Q-005-0065
Caster to Beam Attachment - 80 x 60 mm 4 Q-005-0265
RTE Plug 8 Q-005-1289
Beam to Beam Corner Plate 4 Q-005-1356
64 mm FlexBeam™ Collet 8 Q-005-1426
Fully Threaded - M10 x 120 mm 8 Q-006-1037
Locking Nut M10 42 Q-006-1042
Hex Head - M8 x 16 mm 4 Q-006-1120
Locking Nut M8 16 Q-006-1181
M8 Washer 4 Q-006-1183
M8 x 16 mm Countersunk 16 Q-006-1214
Extra Low Head - M10 x 90 mm 30 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 264 Q-006-1384
Extra Low Head Allen - M10 x 25 mm 12 Q-006-1410
Handle Bar 210 mm M8 2 Q-015-1037
Top plate - 770 x 840 mm 2 Q-016-0086
