Low Rider Tugger Cart - 1120 x 1190 mm
Low Rider Tugger Cart - 1120 x 1190 mm
Low Rider Tugger Cart - 1120 x 1190 mm
Low Rider Tugger Cart - 1120 x 1190 mm
Q-100-1467

Low Rider Tugger Cart - 1120 x 1190 mm

Low rider pallet cart which is designed to transport pallets and containers.

Technical specifications

Category: Flat Deck

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Width: 44 inch

Length: 47 inch

Load capacity: 882 lbs

Type of tow bar: Tongue and Hitch

Transportation method: Manual, Tugger

Caster size: 5 inch

Caster Type: Polyurethane

Type of Load: Pallets and Containers

More info

This low rider pallet cart is designed to transport pallets and containers. It comes equipped with a drop pin and hitch tow bar to connect the carts in a tugger train system. This cart also utilizes corner pallet guides to locate the pallets in the platform easily. The low rider feature helps to load the pallets with special lifting devices.

Parts included
FlexPlate™ 14 Q-002-1001
Flexplate™ M10 2 Q-002-1162
Floor lock COLSON - 4 x 4-1/2 - 125 - 150 mm 1 Q-004-0031
Caster Polyurathane 125 mm 80 x 60 Swivel 4 Q-004-1220
Caster Polyure. 125 mm 80 x 60 Fixed 2 Q-004-1221
L Bracket Joint 4 Q-005-0031
Pallet Guide Corner Plate 4 Q-005-1096
64 mm FlexBeam™ Collet 24 Q-005-1426
Wheel Attachment - 80 x 60 mm 2 Q-005-1722
Hex Head - M14 x 60 mm 4 Q-006-1036
Locking Nut M14 4 Q-006-1039
Hex Head - M10 x 25 mm 9 Q-006-1041
Locking Nut M10 48 Q-006-1042
Washer M10 32 Q-006-1043
Hex Head - M10 x 95 mm 5 Q-006-1088
Hex Head - M10 x 90 mm 12 Q-006-1132
Hex Head - M10 x 30 mm 4 Q-006-1161
Locking Nut M8 24 Q-006-1181
Countersunk - M8 x 20 24 Q-006-1282
Extra Low Head - M10 x 90 mm 13 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 56 Q-006-1384
Countersunk Self Tapping Screw - M6 x 20 40 Q-006-1385
Low Allen Head - M10 x 16 mm 2 Q-006-1409
Extra Low Head Allen - M10 x 25 mm 3 Q-006-1410
FlexHandle low rider w floor lock plate - 700 x 900 mm 1 Q-015-0090
Top Plate - 1120 x 1190 mm 1 Q-016-0792
US Modular Tow Bar VKR - Lip - 380 mm 1 Q-017-0015
Spring Loaded Tow Hinge 1 Q-017-0067
Heavy Duty Tow Hinge - Narrow 1 Q-017-0087
Towing Lip - 28 mm 1 Q-017-1010
FlexBeam™ - 1120 mm 4 Q-020-1120
FlexBeam™ STS FE - 980 mm 2 Q-021-0980
FlexBeam FE - 1050 mm 2 Q-021-1050
