Q-100-1697

Assembly Table - 770 x 2170 mm

Table designed for assembly stations along the assembly line.

100% free. No commitment.

Automotive 794 lbs
load capacity

Assembly Table – 770 x 2170 mm

First Name Last Name Email Company City Country Phone Quantity

Comments (optional) Attach a file (optional) Upload

Maximum file size is 10mb.

We will get back to you within 24 hours. (Unless it’s during holidays.)

Technical specifications

Category	Flat Shelf
Industry	Defense Equipment, Industrial Machinery, Wind & Energy
Width	30 inch
Length	85 inch
Levels	2
Load capacity	794 lbs
Load Capacity per Level	397 lbs
Transportation method	Manual
Caster size	5 inch
Caster Type	Gray
Type of Load	Bins, Boxes, Misc parts, Totes

More info

This cart is designed to be used as an assembly table along the assembly line. On the bottom level, different materials and tools can be stored for easy access. The top level of the table comes with a rubber sheet and is equipped for protecting the materials and components. It also has an attached handlebar, floor-lock brake and four polyurethane casters.

Parts included

Outer tube (No plate) - 657 mm 1 Q-000-0065

FlexTube™ 630 mm 6 Q-000-1312

FlexPlate™ 12 Q-002-1001

125 mm Swivel Caster with Brake 4 Q-004-1364

Floor Lock COLSON 4 x 4-1/2 1 Q-004-1369

T-Joint 4 Q-005-0065

Caster to Beam Attachment - 80 x 60 mm 4 Q-005-0265

Handle for 30 mm Tube 2 Q-005-1240

Floor Brake Plate 1 Q-005-1387

64 mm FlexBeam™ Collet 8 Q-005-1426

Hex Head - M10 x 25 mm 6 Q-006-1041

Locking Nut M10 16 Q-006-1042

Locking Nut M8 16 Q-006-1181

M8 x 16 mm Countersunk 16 Q-006-1214

Extra low head [1,5 mm] M10x40 mm 2 Q-006-1361

Extra Low Head - M10 x 90 mm 8 Q-006-1381

Self Tapping Screw M6 Torx H60 x 16 248 Q-006-1384

Rubber Carpet - 770 x 2170 mm 1 Q-009-0039

FlexBeam™ - 630 mm 2 Q-020-0630

FlexBeam™ FE - 630 mm 4 Q-021-0630
