Roller Transfer Cart - 980 x 980 mm
Roller Transfer Cart - 980 x 980 mm
Roller Transfer Cart - 980 x 980 mm
Roller Transfer Cart - 980 x 980 mm
Q-100-0802

Roller Transfer Cart - 980 x 980 mm

Simply designed transfer cart for containers.

Technical specifications

Category: Standard

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Width: 39 inch

Transportation method: LiftRunner Frames, Manual

Caster size: 8 inch

More info

This is a simple design which is used for transporting containers between different stations. This cart can have a flat deck attached if needed.

Parts included
FlexTube™ 70 mm - Locking Nut 2 Q-000-1101
FlexTube™ 490 mm 2 Q-000-1247
FlexQube 6 Q-001-1078
FlexBeam™ 910 mm 4 Q-001-1304
FlexBeam™ 980 mm FE 2 Q-001-1403
FlexBeam™ 840 mm FE 2 Q-001-1405
FlexPlate™ 14 Q-002-1001
Flexplate™ M10 2 Q-002-1162
Roller Fixture Middle - 980 mm 1 Q-003-0056
Roller Fixture Side - 980 mm 2 Q-003-0057
Roller 200 mm 734105 42 Q-004-1060
Wheel Attachment - 105 x 77,5 mm 4 Q-004-1065
Polyamide Caster 200 mm without Brake 2 Q-004-1352
Polyamide Caster 200 mm Fixed 2 Q-004-1354
Floor Brake LTL - 200 mm 1 Q-004-1359
Locking Guide Plate 2 Q-005-0290
Rotation handle and lock - 420 mm 3 Q-005-0343
Wheel Attachment Box 4 Q-005-1079
Pallet Guide Corner Plate 4 Q-005-1096
Spherical Knob 1 Q-005-1146
Rotation Handle Plunger Guide 1 Q-005-1352
64 mm FlexBeam™ Collet 6 Q-005-1426
Indexing Plunger GN.37313 1 Q-005-1544
M6 x 20 K6S 10.9 Round Head (black) 12 Q-006-1018
Hex Head - M10 x 25 mm 34 Q-006-1041
Locking Nut M10 52 Q-006-1042
Washer M10 3 Q-006-1043
Locking Nut M6 16 Q-006-1050
Hex Head - M10 x 95 mm 2 Q-006-1088
Nut M10 1 Q-006-1195
Extra low head [1,5 mm] M10x40 mm 1 Q-006-1361
Extra Low Head - M10 x 90 mm 4 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 116 Q-006-1384
Extra Low Head Allen - M10 x 25 mm 12 Q-006-1410
Handlebar Attachment EUR 1 Q-015-0026
Handlebar / Floor brake attachment EUR 1 Q-015-0027
Tube for Handlebar EUR 1 Q-015-0033
