Roller Cart - 770 x 490 mm
Roller Cart - 770 x 490 mm
Roller Cart - 770 x 490 mm
Q-100-1209

Roller Cart - 770 x 490 mm

This roller cart is designed to transport boxes and containers.

Technical specifications

Category: Conveyor

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Width: 19 inch

Length: 30 inch

Load capacity: 1323 lbs

Transportation method: Manual

Caster size: 5 inch

Caster Type: Polyurethane

More info

This little roller transfer cart is designed to transport heavy boxes and containers from one station to another safely and ergonomically. The boxes generally are placed onto the conveyor belts after the process is finished. It comes equipped with two rows of rollers, a handlebar, floor brake and four polyurethane casters.

Parts included
FlexTube™ 210 mm 1 Q-000-1224
FlexTube™ 280 mm 1 Q-000-1262
FlexQube 4 Q-001-1078
FlexPlate™ 18 Q-002-1001
Caster Polyurathane 125 mm 80 x 60 Swivel 2 Q-004-1220
Caster Polyure. 125 mm 80 x 60 Fixed 2 Q-004-1221
Floor Lock COLSON 4 x 4-1/2 1 Q-004-1369
Caster to Beam Attachment - 80 x 60 mm 4 Q-005-0265
Locking Guide Plate 2 Q-005-0290
Rotation handle and lock - 420 mm 2 Q-005-0343
L-Bracket Joint - 70 x 70 mm 2 Q-005-0429
Indexing plunger GN 717-8-M12x1,5-B-ST 1 Q-005-0713
Spherical Knob 1 Q-005-1146
Beam to Beam Corner Plate 8 Q-005-1356
64 mm FlexBeam™ Collet 32 Q-005-1426
M6 x 20 K6S 10.9 Round Head (black) 6 Q-006-1018
Hex Head - M10 x 25 mm 6 Q-006-1041
Locking Nut M10 61 Q-006-1042
Locking Nut M6 10 Q-006-1050
Hex Head - M10 x 90 mm 2 Q-006-1132
Locking Nut M8 16 Q-006-1181
M12 Washer 3 Q-006-1205
M8 x 16 mm Countersunk 16 Q-006-1214
Extra low head [1,5 mm] M10x40 mm 1 Q-006-1361
Extra Low Head - M10 x 90 mm 46 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 136 Q-006-1384
Extra Low Head Allen - M10 x 25 mm 6 Q-006-1410
Handlebar / Floor Brake Attachment US 1 Q-015-0029
Handlebar Attachment US 1 Q-015-0031
Tube for handlebar US - 350 mm 1 Q-015-0045
FlexBeam™ FE - 350 mm 12 Q-021-0350
