Pallet Cart - 2240 x 1960 mm
Pallet Cart - 2240 x 1960 mm
Pallet Cart - 2240 x 1960 mm
Pallet Cart - 2240 x 1960 mm
Q-100-1116

Pallet Cart - 2240 x 1960 mm

Tuggable flatbed pallet cart equipped with a handlebar, floor brakes and six polyurethane casters.

Technical specifications

Category: Flat Deck

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Type of tow bar: Tongue and Hitch

Width: 77 inch

Length: 88 inch

Load capacity: 2205 lbs

Transportation method: LiftRunner Frames, Manual

Caster size: 8 inch

Caster Type: Polyurethane

More info

This flatbed pallet cart is great for transportation of larger pallets and containers or several smaller. The cart is equipped with a tow bar, handlebar, floor brakes as well as six high quality polyurethane casters which gives the cart excellent tracking properties and silent movement when connected in a train

Parts included
FlexBeam STS 1890 mm 4 Q-001-1290
FlexBeam™ 910 mm FE 2 Q-001-1404
FlexBeam™ - 1330 mm FE 2 Q-001-1501
FlexBeam 1820 mm STS FE 4 Q-001-1508
FlexBeam STS FE - 2100 mm 2 Q-001-1512
FlexPlate™ 12 Q-002-1001
Stiffener - Outside 1 Q-002-1050
Flexplate™ M10 12 Q-002-1162
Wheel Attachment - 105 x 77,5 mm 2 Q-004-1065
Caster Polyurethane - 200 mm Swivel 4 Q-004-1211
Caster Polyurethan 200 mm Fixed IP2 2 Q-004-1212
US Floor Brake - 200 mm 2 Q-004-1613
L Bracket Joint 8 Q-005-0031
M8 Damper - GN352-30-25-M8-S-55 1 Q-005-0648
Wheel Attachment Box 6 Q-005-1079
Pallet Guide Corner Plate 1 Q-005-1096
Left Angle Corner Plate 1 Q-005-1097
Right Angle Corner Plate 1 Q-005-1099
64 mm FlexBeam™ Collet 38 Q-005-1426
Washer 10,5 x 30 x 2,5 1 Q-006-1030
Hex Head - M14 x 60 mm 2 Q-006-1036
Locking Nut M14 2 Q-006-1039
Hex Head - M10 x 25 mm 58 Q-006-1041
Locking Nut M10 117 Q-006-1042
Washer M10 2 Q-006-1043
Hex Head - M10 x 90 mm 42 Q-006-1132
Locking Nut M8 1 Q-006-1181
Extra Low Head - M10 x 90 mm 10 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 50 Q-006-1384
Countersunk Self Tapping Screw - M6 x 20 88 Q-006-1385
Extra Low Head Allen - M10 x 25 mm 4 Q-006-1410
Hex Head Fully Threaded - M10 x 60 mm 3 Q-006-1502
Handlebar / Floor Brake Attachment US 2 Q-015-0029
Tube for Handlebar US 1 Q-015-0032
Top Plate - 1120 x 980 mm 4 Q-016-0287
US Modular Tow Bar VKR - Lip - 660 mm 1 Q-017-0009
Tow Hinge Module 1 Q-017-0059
Towing Lip - 2,5 Inch 1 Q-017-1012
