Pallet Cart 1820 x 1260 mm
Pallet Cart 1820 x 1260 mm
Pallet Cart 1820 x 1260 mm
Pallet Cart 1820 x 1260 mm
Q-100-0519

Pallet Cart 1820 x 1260 mm

Standard push cart without steel flat deck.

Technical specifications

Category: Standard

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Width: 50 inch

Length: 72 inch

Load capacity: 1102 lbs

Transportation method: Manual

Caster size: 5 inch

Caster Type: Gray

Type of Load: Pallets and Containers

More info

This pallet cart is equipped with an ergonomic handlebar for easier manual transportation. It is designed to transport pallets and containers. It comes with six It comes with a floor lock brake to keep the cart secure when not in use. A tow bar can be added to this cart for transportation in a tugger train.

Parts included
FlexBeam™ 1120 mm 4 Q-001-1301
FlexBeam™ 1050 mm 4 Q-001-1302
FlexBeam™ 700 mm 4 Q-001-1307
FlexBeam™ 1260 mm FE 2 Q-001-1500
FlexPlate™ 12 Q-002-1001
Floor Brake LTL - 125 mm 1 Q-004-1360
Swivel Caster - 125 mm 4 Q-004-1363
Fixed Caster - 125 mm 2 Q-004-1365
Wheel Attachment Box 6 Q-005-1079
Angled Corner Plate 4 Q-005-1098
64 mm FlexBeam™ Collet 8 Q-005-1426
Hex Head - M10 x 25 mm 48 Q-006-1041
Locking Nut M10 72 Q-006-1042
Washer M10 24 Q-006-1043
Extra Low Head - M10 x 90 mm 12 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 48 Q-006-1384
Extra Low Head Allen - M10 x 25 mm 12 Q-006-1410
Handlebar Attachment EUR 1 Q-015-0026
Handlebar / Floor brake attachment EUR 1 Q-015-0027
Tube for Handlebar EUR 1 Q-015-0033
