Kit Cart For Cylinder Blocks - 1260 x 1260 mm
Kit Cart For Cylinder Blocks - 1260 x 1260 mm
Kit Cart For Cylinder Blocks - 1260 x 1260 mm
Kit Cart For Cylinder Blocks - 1260 x 1260 mm
Kit Cart For Cylinder Blocks - 1260 x 1260 mm
Kit Cart For Cylinder Blocks - 1260 x 1260 mm
Kit Cart For Cylinder Blocks - 1260 x 1260 mm
Q-100-0203

Kit Cart For Cylinder Blocks - 1260 x 1260 mm

Tuggable flatbed pallet cart with a rail. The cart comes equipped with a handlebar and four polyurethane casters, two fixed and two swivel.

Technical specifications

Transportation method: Manual, Tugger

Industry: Defense Equipment, Industrial Machinery, Wind & Energy

Category: Kitting Carts

Length: 50 inch

Width: 50 inch

Load capacity: 2000 lbs

Caster size: 8 inch

Caster Type: Polyurethane

More info

Tuggable flatbed cart commonly used for the transportation of pallets and containers. The deck gives you the option load the cart with several different sizes and a rail has been added to keep parts from falling off during transportation. The cart is equipped with a handlebar, tow bar, and four polyurethane casters, two fixed and two swivels giving you excellent tracking properties and silent movement in a train.

Parts included
FlexTube™ 210 mm 4 Q-000-1224
FlexTube™ 1120 mm 4 Q-000-1258
FlexQube 8 Q-001-1078
FlexBeam™ 1190 mm 6 Q-001-1300
FlexBeam™ 630 mm 2 Q-001-1308
FlexBeam™ 1260 mm FE 2 Q-001-1500
FlexPlate™ 12 Q-002-1001
Stiffener - Outside 4 Q-002-1050
Caster Polyurethane 200 mm Fixed 2 Q-004-1101
Caster Polyurethan Fix Brake - 200 mm 2 Q-004-1111
M8 Damper - GN352-30-25-M8-S-55 1 Q-005-0648
Spring Cover Plate 1 Q-005-1025
Wheel Attachment Box 4 Q-005-1079
Hex Head M14 x 90 mm 1 Q-005-1406
64 mm FlexBeam™ Collet 16 Q-005-1426
Allen Head - M6 x 16 mm 4 Q-006-1011
Allen Head - M6 x 30 mm 12 Q-006-1012
Washer 10,5 x 30 x 2,5 1 Q-006-1030
Locking Nut M14 1 Q-006-1039
Hex Head - M10 x 25 mm 18 Q-006-1041
Locking Nut M10 65 Q-006-1042
Washer M10 58 Q-006-1043
M6 Washer 48 Q-006-1076
Hex Head - M10 x 95 mm 2 Q-006-1088
Hex Head - M10 x 90 mm 10 Q-006-1132
Hex Head - M10 x 30 mm 16 Q-006-1161
Locking Nut M8 1 Q-006-1181
Extra Low Head - M10 x 90 mm 4 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 174 Q-006-1384
Extra Low Head Allen - M10 x 25 mm 8 Q-006-1410
Hex Head Fully Threaded - M10 x 60 mm 7 Q-006-1502
Spring 1,5 x 15yd x 70 1 Q-012-1141
Handlebar Attachment US 2 Q-015-0031
Tube for Handlebar US 1 Q-015-0032
Plate 49 x 24,5 Inch 2 Q-016-1110
US Modular Tow Bar VKR - Foot Release - 670 mm 1 Q-017-0012
Foot Release Locking Lip 1 Q-017-0024
Tow Hinge Module 1 Q-017-0059
Locking lip attachment 1 Q-017-1043
Tow Hole 28 mm - Symmetric 1 Q-017-1066
Towing Lock Pin US 1 Q-017-1105
39 mm Sleeve for M10 US 2 Q-017-1106
