Flex Shelf Cart -1190 x 700 mm-v2
Flex Shelf Cart -1190 x 700 mm-v2
Flex Shelf Cart -1190 x 700 mm
Flex Shelf Cart -1190 x 700 mm
Q-100-1217

Flex Shelf Cart -1190 x 700 mm-v2

Flat shelf cart with four removable shelves designed to transport bins, totes and boxes.

Technical specifications

Category: Flat Shelf

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Width: 28 inch

Length: 47 inch

Levels: 4

Load capacity: 1102 lbs

Load Capacity per Level: 331 lbs

Transportation method: Manual

Caster size: 8 inch

Caster Type: Polyurethane

Type of Load: Bins, Boxes, Misc parts, Totes

More info

This cart is made with four removable shelves and can be used for transportation of boxes, totes or loose components. The wire mesh covers the rear and sides of the cart, keeping the parts secured inside. The cart is equipped with polyurethane casters in a diamond configuration, a rubber sheet in the bottom level is also added for extra protection of the parts. Forklift guides and a couple of dampers for absorbing impact when placed in the rows are also attached.

Parts included
FlexBeam™ - 1330 mm 8 Q-001-1298
FlexBeam™ 1120 mm 4 Q-001-1301
FlexBeam™ 700 mm FE 2 Q-001-1407
FlexBeam™ 560 mm FE 2 Q-001-1409
FlexPlate™ 8 Q-002-1001
Flexplate™ M10 16 Q-002-1162
Flexplate™ 30,5 mm hole 16 Q-002-1320
FlexPlate™ half 6 Q-002-1369
Wheel Attachment - 105 x 77,5 mm 4 Q-004-1065
Caster Polyurethane 200 mm with Brake 2 Q-004-1099
Caster Polyurethan 200 mm Fixed IP2 2 Q-004-1212
Spring Threaded Tube Connectors 24 Q-005-0469
Rubber Damper Threaded Stud - 70 x 55 mm 2 Q-005-0743
Fork Protection 2 Q-005-1075
U-Plate 2 Q-005-1078
Shelf 700 x 595 mm with Holes 8 Q-005-1342
Beam to Beam Corner Plate 4 Q-005-1356
64 mm FlexBeam™ Collet 28 Q-005-1426
Fence - 1145 x 1400 mm 1 Q-005-1508
Fence - 655 x 1400 mm 2 Q-005-1510
Rubber Carpet 1 Q-005-1511
M6 x 20 K6S 10.9 Round Head (black) 12 Q-006-1018
Washer 10,5 x 30 x 2,5 22 Q-006-1030
Fully Threaded - M10 x 120 mm 4 Q-006-1037
Locking Nut M10 52 Q-006-1042
Hex Head - M10 x 95 mm 28 Q-006-1088
Hex Head - M10 x 40 16 Q-006-1208
Extra Low Head - M10 x 90 mm 20 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 136 Q-006-1384
Countersunk Self Tapping Screw - M6 x 20 46 Q-006-1385
Extra Low Head Allen - M10 x 25 mm 2 Q-006-1410
Outer Tube (No Plate) - 1190 mm 8 Q-025-1190
