Totes Trolley 24 x 15 inch
Totes Trolley 24 x 15 inch
Totes Trolley 24 x 15 inch
Totes Trolley 24 x 15 inch
Q-100-0244

Totes Trolley 24 x 15 inch

Standard trolley for transporting totes.

Technical specifications

Category: Flat Deck

Industry: Appliances & Electronics, Distribution, Medical Equipment

Length: 24 inch

Width: 17 inch

Load capacity: 220 lbs

Transportation method: LiftRunner Frames, Manual

Caster size: 5 inch

Caster Type: Polyamide

More info

This is a basic totes trolley for transporting totes, bins and boxes. It is compatible with the STILL LiftRunner E-Frame for transportation in a tugger train system.

Parts included
Swivel Caster - 125 mm 4 Q-004-1363
U-Profile for - 24 x 15 inch 2 Q-005-0172
Hex Head Fully Threaded - M8 x 20 mm 16 Q-006-1019
Locking Nut M10 4 Q-006-1042
Locking Nut M8 16 Q-006-1181
Extra Low Head Allen - M10 x 25 mm 4 Q-006-1410
Box - 24 x 15 inch 1 Q-016-0106
Rubber Corner Protection 2 Q-011-1003
