Low Rider tugger cart – 1120 x 1190 mm
Low Rider tugger cart – 1120 x 1190 mm
Low Rider tugger cart – 1120 x 1190 mm
Low Rider tugger cart - 1120 x 1190 mm
Q-100-1467

Low Rider tugger cart – 1120 x 1190 mm

Low rider pallet cart which is designed to transport pallets and containers.

Technical specifications

Category: Flat Deck

Industry: Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy

Width: 1120 mm

Length: 1190 mm

Load capacity: 400 kg

Type of tow bar: Tongue and Hitch

Transportation method: Manual, Tugger

Caster size: 125 mm

Caster Type: Polyurethane

Type of Load: Pallets and Containers

More info

This low rider pallet cart is designed to transport pallets and containers. It comes equipped with a drop pin and hitch tow bar to connect the carts in a tugger train system. This cart also utilises corner pallet guides to store the pallets easily on the platform. The low rider feature helps to load the pallets with special lifting devices.

Parts included
FlexPlate™ 14 Q-002-1001
Flexplate™ M10 2 Q-002-1162
Floor lock COLSON – 4" x 4–1/2" – 125 – 150 mm 1 Q-004-0031
Caster Polyurethane 125 mm 80 x 60 Swivel 4 Q-004-1220
Caster Polyure. 125 mm, 80 x 60, Fixed 2 Q-004-1221
L Bracket Joint 4 Q-005-0031
Pallet Guide Corner Plate 4 Q-005-1096
64 mm FlexBeam™ Collet 24 Q-005-1426
Wheel Attachment – 80 x 60 mm 2 Q-005-1722
M14 x 60 mm Hex Head 4 Q-006-1036
Locking Nut M14 4 Q-006-1039
M10 x 25 mm Hex Head 9 Q-006-1041
Locking Nut M10 48 Q-006-1042
Washer M10 32 Q-006-1043
M10 x 95 mm Hex Head 5 Q-006-1088
M10 x 90 mm Hex Head 12 Q-006-1132
M10 x 30 mm Hex Head 4 Q-006-1161
Locking Nut M8 24 Q-006-1181
M8 x 20 Countersunk 24 Q-006-1282
M10 x 90 mm Extra Low Head 13 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 56 Q-006-1384
M6 x 20 Countersunk Self Tapping Screw 40 Q-006-1385
M10 x 16 mm Low Allen Head 2 Q-006-1409
M10 x 25 mm Extra Low Head Allen 3 Q-006-1410
FlexHandle – 700 x 900 mm low rider w floor lock plate 1 Q-015-0090
Top Plate – 1120 x 1190 mm 1 Q-016-0792
US Modular Tow Bar VKR 380 mm – Lip 1 Q-017-0015
Spring Loaded Tow Hinge 1 Q-017-0067
Heavy Duty Tow Hinge – Narrow 1 Q-017-0087
Towing Lip – 28 mm 1 Q-017-1010
FlexBeam™ – 1120 mm 4 Q-020-1120
FlexBeam™ 980 mm STS FE 2 Q-021-0980
FlexBeam FE – 1050 mm 2 Q-021-1050
